● 32-65536 level control, can restore the true color and detail image;
● 512 level tricolor independent brightness control, accurate white balance adjustment is more simple andeffective;
● Adjusted according to the physiological characteristics of human visual hardware inverse gammacorrection function;
● The 100Hz refresh rate can ensure the stability of the picture;
● Adopt the Ethernet interface and UDP network protocol, the maximum transmission distance is 100meters;
● The display module can display controller parameters and the state;
● The controller output is compatible with TTL signal and differential signal dual mode;
● The multi chip control set in one, set up by the software control chip type,OE clock frequency, period, dutyratio, gray level and other parameters change;
● Double network interface,can realize the controller controller cascade; automatic detection, displayconnection status;
●The 512 driver online addressing support 512 types:
DMX12AP,UCS512;SM16512;SM16511; UCS512C; UCS512C4; TM512; WS2821;DMX512x;
● Each port can drive 1024,3072 channel;
●The 8 independent output port, each port is isolated.
